Accelerate Your Learning and Design Process with the EC200U Evaluation Board

Evaluation boards can greatly assist you in experimenting, testing, designing, and generally speeding up the learning and product design processes, freeing your mind from getting bogged down with peripheral technical issues. This educational board is designed for the EC200U module from Quectel, allowing you to quickly set up the module and familiarize yourself with its capabilities.

Overview of Quectel EC200U Series

The Quectel EC200U series is a cutting-edge LTE Cat 1 module specifically optimized for Machine-to-Machine (M2M) and Internet of Things (IoT) applications. It delivers impressive maximum data rates of up to 10 Mbps for downlink and 5 Mbps for uplink, making it suitable for various connectivity needs in modern applications.

Compatibility and Design

Designed in a compact and unified form factor, the EC200U series is compatible with several Quectel multi-mode LTE standards, including the EC25 series, EC21 series, EC20 R2.1, EC20-CN, EC200T series, EC200S series, EC25-G, EC21-G, and UMTS/HSPA+ UC200T series. This compatibility ensures a seamless migration from 3G to 4G networks. Additionally, the EC200U series supports standard Mini PCIe packages, catering to the diverse requirements of different industry applications.

Variants and Aesthetics

The EC200U series includes two variants: EC200U-CN and EC200U-EU, which are designed to meet the frequency band coverage requirements of various countries and regions. Utilizing a laser engraving process, the EC200U series boasts a stylish appearance, a strong metallic texture, enhanced heat dissipation capabilities, and durable label information. These features make it particularly well-suited for automation requirements.

Functionality and Applications

The EC200U series is equipped with a rich set of Internet protocols, industry-standard interfaces, and a wide array of functionalities. It includes USB drivers compatible with Windows 7/8/8.1/10, Linux, and Android, which broadens the module’s applicability across numerous M2M and IoT applications. These applications include Point of Sale (POS), Point of Care (POC), Electronic Toll Collection (ETC), shared equipment, data cards, energy control and monitoring, security and protection systems, and industrial Personal Digital Assistants (PDAs).

Downloads

• Quectel_EC200U_Series_Hardware_Design_V1
• Quectel_EC200U_Series_LTE_Standard_Specification_V1.1
• Quectel_EC200UEG915U_Series_AT_Commands_Manual_V1.0
• Quectel_ECx00UEGx00U_Series_GNSS_Application_Note_V1.0
• LTE_EVB_A Series Schematic
